Marine Isolation Transformer
Overview
Marine-Puck transformers feature a toroidal isolation transformer, which is embedded in solid Epoxy resin and contained in a cup shaped Polycarbonate (LEXAN) enclosure. Shore side and boat side power cords protrude from the epoxy potting material and seal the transformer hermetically from the outside meaning that the transformer can be mounted on board, inside or outside onto a deck or bulkhead wherever convenient. Installing a Marine-Puck lowers leakage current to less than 1 milliampere, far exceeding the protection level of any commercial GFI device.
Marine-Puck transformers feature a toroidal isolation transformer, which is embedded in solid Epoxy resin and contained in a cup shaped Polycarbonate (LEXAN) enclosure. Shore side and boat side power cords protrude from the epoxy potting material and seal the transformer hermetically from the outside meaning that the transformer can be mounted on board, inside or outside onto a deck or bulkhead wherever convenient. Installing a Marine-Puck lowers leakage current to less than 1 milliampere, far exceeding the protection level of any commercial GFI device.
| Input Voltage AC | 120V or 240V |
|---|---|
| Output Voltage |
120V or 240V |
| Output Curent | 50A/120V or 25A/240V |
| Impedance% | 2.8% |
| kVA Continuous | 6kVA |
| Insulation Class |
B130C |
| Hi-Pot Test Voltage | 4000V AC RMS |
| Ambient Temperature |
-20 to +40 degrees C |
| Dimensions | 12.6″ OD x 6.5″ Ht. |
| Approx. Weight | 75 lbs |
| Main Mount | 1/2″ carriage bolt |
